Application

P50mm B Series Black Frame LED Video Wall Screen

Pixel Pitch50mm
Pixel Density400 dot/m²
LED Type1 / 2 / 3 * RGB 3IN1 SMD3535
Brightness1000 / 1800 / 2500 (cd/m²)
Max. Power Consumption 180 / 240 / 300 (W/m²)
Ave. Power Consumption60 / 80 / 100 (W/m²)
Transparency75%
Viewing Distance10m~300m
Screen Weight4.6 kg/m²
Module Resolution8dots*250dots max.
Fire Protection RatingUL94-V0
IP RateIP67
Control SystemNovaStar
Dot Size20mm(L) * 18mm *18mm(H)
Viewing Angle120°(H)/120°(V)
Housing MaterialTransparent PC
Refresh Rate≥1920Hz
Gray Scale16 Bits
Working EnvironmentTemperature -30℃~+60℃，Humidity10~90% RH
Input (Working) VoltageAC110~ 240V, 50/60Hz (DC12V)
Scan ModeStatic Scanning

Inquire Now

LED Video Wall Screen Features

LED Video Wall Screen Accesories

Hanging Beam

Stainless-Steel Wire Rope

Stainless U-Shaped Buckle

Stainless-Steel Wire Tensioner

NovaStar Controller

Rain-proof Power Supply

LED Video Wall Screen Quick Installation

Fast installation on the stage to save your time and labour. No complex frame required, when fixing the huge mesh screen on the building facade.

LED Video Wall Screen System Connection

LED Video Wall Screen After Install

LED Video Wall Screen Projects

Commerical mall advertisement

Large scale lake performance

Commercial streets Lighting

Bridge Facade Lighting

LED Video Wall Screen Applications Video Show

Through the led video wall screen actual engineering projects show different scenes application effects. These cases usually include lighting design schemes and actual renderings of such as city squares, parks, Bar, Hotel, Mall and building exterior walls. By understanding these cases, people can better understand the application of led mesh screen in practical projects and their beautification effect on urban night scenes. Kote Long Opto Co., Ltd has more than 700 application cases in the world, selling well in more than 60 countries and regions.
